The MB-SPS-Compact is our single solvent purification system specifically designed for customers who demand a compact more economical solution in their solvent purification needs. The compact design and high quality construction allows customers the ability to dispense ultra pure solvents directly from the laboratory bench top.

Features include double valve shutoff, over pressure valve, a completely stainless steel front panel which resists corrosion from solvents and an optional adjustable jack stand for the correct positioning of the collection vessel. The MB SPS Compact is also available with an independent regulator to control solvent flow into the glassware and glovebox integration ready piping for future dispensing directly in the glovebox.

In addition MBRAUN SPS systems can integrate seamlessly with third party solvent providers such as Sigma Aldrich®, FisherPaks®and JT Baker®. All Solvent purification systems can be designed and configured to meet your specific application needs.


Please note: Specification may vary depending on configuration.

  • Type: Encapsulated solvent purification system
  • External dimensions: 275 mm (w) x 914 mm (h) x 420 mm (d)
  • System control: Manual
  • Operation: Hand valves dispense solvent
  • Material: Stainless steel (1.4301 / us 304)
  • Leveling feet: Yes
  • Manifold: Stainless steel piping w/ three way hand valve
  • Work shelf: Optional jack stand available
  • Vacuum pump: Oil free diaphragm pump (optional)
  • Solvent flow rate: <1,000 ml / minute
  • Electrical power: 230v / 50-60hz, 10 amps, 115v / 50-60 hz, 15 amps
  • Safety cabinet: Optional
  • Vapor removal: Vapor removal with 4″ connection & emergency cut-off valve
  • Process: Closed loop system
  • Dispensing: From the sps system, inside glovebox, or combination of both
  • Working gas: Nitrogen or argon (typically a nitrogen source of 99.99% purity or better)
  • Solvent regulation: Independent regulator for each solvent
  • Solvent line material: Color coded stainless steel line (1.4301 / us 304)
  • Inlet pressure: Inlet pressure set between 4.0 bar and 6.0 bar
  • Working pressure: Working pressure set between 0.3 bar and 0.5 bar
  • Filter type: Double column solvent filtration
  • Filter column: Two stainless steel columns per solvent (1.4301 / us 304)
  • Filter column size: 4.8l (1 gallon)
  • Particle filtration: Filter columns equipped w/ pre-filters
  • Filter material: Depends on solvent type
  • Filter column capacity: Up to 800l
  • Filter column activation: Columns activated before shipment
  • Attainable purity: Attainable purity varies according to solvent type
  • Material: Stainless steel reservoir (1.4301 / us 304)
  • Capacity: 17l (optional sizes available)
  • Piping: Stainless steel 1/4″ piping w/ swagelok fittings & 1/4″
